Catéter de angioplastia, dilatación con balón, no coronario

PTA

**Registro en trámite**

0 out of 5 based on 0 customer ratings

Catéter de angioplastia, dilatación con balón, no coronario

Category:

– Varios tamaños disponibles para diversas lesiones
– Estructura de tubo para un inflado y desinflado rápido
– Excelente resistencia a la flexión del eje

Características
Modelo GPC
Presión nominal
12ATM: Ø4, Ø5, Ø6, Ø7, Ø8
11ATM: Ø9
10ATM: Ø10, Ø12Presión nominal de rotura
18ATM: Ø4, Ø5, Ø6, Ø7 (menos de 80 mm), Ø8
16ATM: Ø7 (más de 100 mm), Ø9
14ATM: Ø10, 12
Modelo GNPC
Presión nominal
12ATM: Ø4, Ø5, Ø6, Ø7, Ø8
11ATM: Ø9
10ATM: Ø10, Ø12Presión nominal de rotura
23ATM: Ø4 (menos de 0 mm), Ø5 (menos de 80 mm), Ø6 (menos de 80 mm), Ø7 (menos de 80 mm)
20ATM: Ø4 (más de 80 mm), Ø5 (más de 100 mm), Ø6 (más de 100 mm), Ø7 (más de 100 mm)
18ATM: Ø8
16ATM: Ø9
17ATM: Ø10, Ø12
Nombre del modelo (modelo GPC)
Longitud del catéter utilizable: 50 cm
 Diámetro del globo (mm) Longitud del globo
20 40 60 80 100 120
4 GPC-04-020-050 GPC-04-040-050 GPC-04-060-050 GPC-04-080-050 GPC-04-100-050 GPC-04-120-050
5 GPC-05-020-050 GPC-05-040-050 GPC-05-060-050 GPC-05-080-050 GPC-05-100-050 GPC-05-120-050
6 GPC-06-020-050 GPC-06-040-050 GPC-06-060-050 GPC-06-080-050 GPC-06-100-050 GPC-06-120-050
7 GPC-07-020-050 GPC-07-040-050 GPC-07-060-050 GPC-07-080-050 GPC-07-100-050 GPC-07-120-050
8 GPC-08-020-050 GPC-08-040-050 GPC-08-060-050 GPC-08-080-050 – –
9 GPC-09-020-050 GPC-09-040-050 GPC-09-060-050 GPC-09-080-050 – –
10 GPC-10-020-050 GPC-10-040-050 GPC-10-060-050 – – –
12 GPC-12-020-050 GPC-12-040-050 GPC-12-060-050 – – –
Longitud del catéter utilizable: 80 cm
4 GPC-04-020-080 GPC-04-040-080 GPC-04-060-080 GPC-04-080-080 GPC-04-100-080 GPC-04-120-080
5 GPC-05-020-080 GPC-05-040-080 GPC-05-060-080 GPC-05-080-080 GPC-05-100-080 GPC-05-120-080
6 GPC-06-020-080 GPC-06-040-080 GPC-06-060-080 GPC-06-080-080 GPC-06-100-080 GPC-06-120-080
7 GPC-07-020-080 GPC-07-040-080 GPC-07-060-080 GPC-07-080-080 GPC-07-100-080 GPC-07-120-080
8 GPC-08-020-080 GPC-08-040-080 GPC-08-060-080 GPC-08-080-080 – –
9 GPC-09-020-080 GPC-09-040-080 GPC-09-060-080 GPC-09-080-080 – –
10 GPC-10-020-080 GPC-10-040-080 GPC-10-060-080 – – –
12 GPC-12-020-080 GPC-12-040-080 GPC-12-060-080 – – –
Longitud del catéter utilizable: 130 cm
4 GPC-04-020-130 GPC-04-040-130 GPC-04-060-130 GPC-04-080-130 GPC-04-100-130 GPC-04-120-130
5 GPC-05-020-130 GPC-05-040-130 GPC-05-060-130 GPC-05-080-130 GPC-05-100-130 GPC-05-120-130
6 GPC-06-020-130 GPC-06-040-130 GPC-06-060-130 GPC-06-080-130 GPC-06-100-130 GPC-06-120-130
7 GPC-07-020-130 GPC-07-040-130 GPC-07-060-130 GPC-07-080-130 GPC-07-100-130 GPC-07-120-130
8 GPC-08-020-130 GPC-08-040-130 GPC-08-060-130 GPC-08-080-130 – –
9 GPC-09-020-130 GPC-09-040-130 GPC-09-060-130 GPC-09-080-130 – –
10 GPC-10-020-130 GPC-10-040-130 GPC-10-060-130 – – –
12 GPC-12-020-130 GPC-12-040-130 GPC-12-060-130 – – –



Nombre del modelo (modelo GNPC)
Longitud del catéter utilizable: 50 cm
 Diámetro del globo (mm) Longitud del globo
20 40 60 80 100 120
4 GNPC-04-020-050 GNPC-04-040-050 GNPC-04-060-050 GNPC-04-080-050 GNPC-04-100-050 GNPC-04-120-050
5 GNPC-05-020-050 GNPC-05-040-050 GNPC-05-060-050 GNPC-05-080-050 GNPC-05-100-050 GNPC-05-120-050
6 GNPC-06-020-050 GNPC-06-040-050 GNPC-06-060-050 GNPC-06-080-050 GNPC-06-100-050 GNPC-06-120-050
7 GNPC-07-020-050 GNPC-07-040-050 GNPC-07-060-050 GNPC-07-080-050 GNPC-07-100-050 GNPC-07-120-050
8 GNPC-08-020-050 GNPC-08-040-050 GNPC-08-060-050 GNPC-08-080-050 – –
9 GNPC-09-020-050 GNPC-09-040-050 GNPC-09-060-050 GNPC-09-080-050 – –
10 GNPC-10-020-050 GNPC-10-040-050 GNPC-10-060-050 – – –
12 GNPC-12-020-050 GNPC-12-040-050 GNPC-12-060-050 – – –
Longitud del catéter utilizable: 80 cm
4 GNPC-04-020-080 GNPC-04-040-080 GNPC-04-060-080 GNPC-04-080-080 GNPC-04-100-080 GNPC-04-120-080
5 GNPC-05-020-080 GNPC-05-040-080 GNPC-05-060-080 GNPC-05-080-080 GNPC-05-100-080 GNPC-05-120-080
6 GNPC-06-020-080 GNPC-06-040-080 GNPC-06-060-080 GNPC-06-080-080 GNPC-06-100-080 GNPC-06-120-080
7 GNPC-07-020-080 GNPC-07-040-080 GNPC-07-060-080 GNPC-07-080-080 GNPC-07-100-080 GNPC-07-120-080
8 GNPC-08-020-080 GNPC-08-040-080 GNPC-08-060-080 GNPC-08-080-080 – –
9 GNPC-09-020-080 GNPC-09-040-080 GNPC-09-060-080 GNPC-09-080-080 – –
10 GNPC-10-020-080 GNPC-10-040-080 GNPC-10-060-080 – – –
12 GNPC-12-020-080 GNPC-12-040-080 GNPC-12-060-080 – – –
Longitud del catéter utilizable: 130 cm
4 GNPC-04-020-130 GNPC-04-040-130 GNPC-04-060-130 GNPC-04-080-130 GNPC-04-100-130 GNPC-04-120-130
5 GNPC-05-020-130 GNPC-05-040-130 GNPC-05-060-130 GNPC-05-080-130 GNPC-05-100-130 GNPC-05-120-130
6 GNPC-06-020-130 GNPC-06-040-130 GNPC-06-060-130 GNPC-06-080-130 GNPC-06-100-130 GNPC-06-120-130
7 GNPC-07-020-130 GNPC-07-040-130 GNPC-07-060-130 GNPC-07-080-130 GNPC-07-100-130 GNPC-07-120-130
8 GNPC-08-020-130 GNPC-08-040-130 GNPC-08-060-130 GNPC-08-080-130 – –
9 GNPC-09-020-130 GNPC-09-040-130 GNPC-09-060-130 GNPC-09-080-130 – –
10 GNPC-10-020-130 GNPC-10-040-130 GNPC-10-060-130 – – –
12 GNPC-12-020-130 GNPC-12-040-130 GNPC-12-060-130 – – –
